Surface finishing | Services

Name	Applicable Materials	Colors	Can be applied to
As machined	Aluminum, Steel, Stainless Steel	Ra 0.8μm - Ra 3.2μm	All post processes
Anodizing	Aluminum	Clear, black, grey, red, blue,green,orange,gold	Media Blasting, Tumbling, Alodine*
Chrome Plating	Acrylic	n/a	Enhanced Cosmetic Appearance
Electroless Nickel Plating	Aluminum, Steel, Stainless Steel	n/a	Media Blasting, Tumbling
Black Oxide	Aluminum	Black	Bead blasted, Tumbling, Chem film*
Bead Blasted + Anodized type II	Aluminum	Clear, Black, Red, Blue, Orange, Gold	Media Blasting, Tumbling, Type II Anodizing* Type III Anodizing with PTFE*
Zinc Plating	Steel, Stainless Steel	Clear (light blue coating). Black (glossy black coating).	Media Blasting, Tumbling, Passivation
Tumbling	Aluminum, Steel, Stainless Steel, Brass, Bronze, Copper	n/a	All post processes, except Electropolish and Powder Coat
Nano coating	For applicable material processing, please refer to the catalog.	Full Coating or RAL color catalog	Please contact us for detailed instructions
Passivation	Steel, Stainless Steel	n/a	Black Oxide, Electroless Nickel Plating, Zinc Plating, Tumbling, Media Blasting
Brushed	Aluminum, Steel, Stainless Steel, Brass, Bronze, Copper	Small：Draw 6.5-8mm wire to 2.0-4.0mm. Medium：Draw 16-18mm wire to 8.0-12.0mm. Large：Draw 100-120mm wire to 20-30mm.	All post processes, except Electropolish and Powder Coat
Electropolishing	Steel, Stainless Steel	n/a	Passivation, Tumbling

*Additional finishing options include chromic acid anodizing, cadmium plating, copper plating, titanium anodizing (blue anodizing), gold plating, silver plating, and more. For materials not listed here, please contact us directly.

Cosmetic finishes

Surface finishes can serve either a functional or aesthetic purpose. Surface finishes that serve both purposes are deemed cosmetic finishes, and are used for cosmetic parts. Producing cosmetic parts requires additional measures to minimize defects such as hang marks and scratches from tools.

Non-cosmetic

Primary machining marks will still be visible

As machined
Smooth machining
Fine machining
Electroless Nickel Plating
Anodized type III (Hardcoat)
Black oxide

Cosmetic on request

Finishes can be either cosmetic or non-cosmetic as per request

Brushed + Anodizing type II
Bead Blasted + Anodizing type II
Bead Blasted
Brushed
Nano coating

Cosmetic by default

These finishes will always serve a cosmetic function

Brushed + Electropolished
Polishing

Gallery of Surface finishing parts

Below are a small selection of the CNC machined parts and end-use components we produce for our customers.

Medical stainless steel parts

Features: corrosion resistance, high temperature resistance, high strength. Applications: Medical equipment, chemical containers, etc.

Drone fixed bracket parts

Drones need to minimize weight as much as possible to enhance flight efficiency, and aluminum alloy, with its low density but high strength, makes it an ideal material for fixed rotor supports.

Drone bracket parts

Drones need to minimize weight as much as possible to improve flight efficiency, and aluminum alloy, with its low density but high strength, makes it an ideal material for brackets.

Drone propeller bracket parts

The wings and rotors of drones are crucial components for generating lift and maintaining flight attitude. Aluminum alloy, due to its high strength and lightweight properties, is often used to manufacture these components.

Action camera rabbit cage parts

The low density of aluminum alloy results in an overall lightweight design for the phone cage, making it easy to carry and use for extended periods without causing excessive strain for photographers.

Intelligent robot parts

The application of aluminum alloy in robotic joints is extensive, primarily benefiting from its lightweight nature, high strength, wear resistance, and excellent processing properties.

Material Suitability

This involves choosing metallic materials that are suitable based on processing needs and product usage. For instance, aluminum alloy may be a good choice for products that require high corrosion resistance and aesthetics, but attention should be paid to its processing characteristics and potential surface issues.
